Saturn Sky I (2006-2009) high spd gmlan ser data bus + high spd gmlan ser data bus + Wiring diagram

ANTI-LOCK BRAKES SYSTEM BODY CONTROL MODULE (RIGHT OF HVAC MODULE) BRAKE PEDAL POSITION SNSR SIG BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL SWITCH SIGNAL CRUISE CONTROL SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRL AMBIENT LIGHT SENS LOW REF DRL AMBIENT LIGHT SENS SIG FLASH TO PASS SW SIG GRY WIRE HAZARD SWITCH SIG REAR COMPT LID RELEASE SW SECURITY IND CTRL HEADLAMP SW SIG HEADLAMP DIM SW HIGH BEAM SIG PARK LAMP SWITCH SIG HEADLIGHTS SYSTEM HIGH SPD GMLAN SER DATA BUS + HIGH SPD GMLAN SER DATA BUS + HIGH SPD GMLAN SRL DATA BUS - HIGH SPD GMLAN SRL DATA BUS - HORN RLY CTRL HEADLAMP SW ON SIG FRONT FOG LAMP SW SIG HEADLAMP SW OFF SIG IGNITION SWITCH KEY-IN SWITCH LEFT TURN SIG SW SIG RIGHT TURN SIG SW SIG REAR DEFOG SW SIG A/C REQUEST SIGNAL LOGIC LOW SPD GMLAN SERIAL DATA LT BLU WIRE LT GRN/BLK WIRE OFF OFF/RUN/CRANK VOLTAGE WINDSHIELD WIPER SW SIG 1 LOW REFERENCE LOW REFERENCE ORG/ WIRE PASS SEAT BELT IND REAR DEFOG RELAY CONTROL PNK/WHT WIRE PNL LAMPS DIM SW SIG PPL PPL/WHT WIRE RED WIRE RED/WHT WIRE RUN WIRE SUPPLEMENTAL RESTRAINTS SYSTEM DEFOGGER SYSTEM TAN WIRE TAN/BLK WIRE WHT WIRE WHT/BLK WIRE WIPER/WASHER SYSTEM INTERIOR LIGHTS SYSTEM ANTI-LOCK BRAKES SYSTEM YEL WIRE YEL/BLK WIRE
