Saturn Sky I (2006-2009) ground aud common drain Wiring diagram
This page shows the only wiring diagram for the component.ground aud common drain, which is found in the car Saturn Sky I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground aud common drain (1 of 1)
1 2 9 L AUDIO SIG (+) R AUDIO SIG (+) AUDIO COMMON
ANTENNA SIG
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
COAX
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER
DK GRN WIRE
DK GRN/WHT WIRE
GROUND AUD COMMON DRAIN
HOT AT ALL TIMES
L AUD SIG + R AUD SIG +
NCA WIRE
RADIO
RED WIRE
RED/WHT WIRE
S BAND ONSTAR/RKE FUSE 56
SATELLITE ANTENNA
SERIAL DATA
TAN/WHT WIRE
UNDERHOOD FUSE BLOCK (IN RIGHT REAR CORNER OF ENGINE COMPT)
WHT WIRE
Go to component -> Satellite radio circuit -> GROUND AUD COMMON DRAIN
