Saturn Sky I (2006-2009) data high serial Wiring diagram
This page shows the only wiring diagram for the component.data high serial, which is found in the car Saturn Sky I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data high serial (1 of 1)
ABS IND.
BLK WIRE
BODY CONTROL MODULE (BCM) (RIGHT OF HVAC MODULE)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL LEVER)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA
DATA BUS -
DATA HIGH SERIAL
DK GRN WIRE
GRY WIRE
GRY/BLK WIRE
HIGH SERIAL DATA
HOT IN RUN OR START
HVAC/ IP IGN FUSE
IGN
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW REFERENCE
LOW SERIAL
LOW SERIAL DATA
LT BLU WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PNK WIRE
PNK/BLK WIRE
SENSOR SIGNAL
SERIAL DATA
SPLICE PACK
SW SIG
TAN WIRE
TAN/BLK WIRE
TRACTION CONTROL SWITCH (W/ TRACTION CONTROL, ACTIVE BRAKE CONTROL)
TRACTION CTRL
WHT WIRE
YEL WIRE
Go to component -> 2.0l, anti-lock brakes circuit (2 of 2) -> DATA HIGH SERIAL
