Satellite radio circuit for Saturn Outlook I (2006-2010)

Satellite radio circuit

Get access

16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 B+ ANTENNA SIG BARE BARE (BLUNT CUT SHIELD) BLK/WHT WIRE BRN/WHT WIRE COAX COMPUTER DATA LINES SYSTEM DIGITAL RADIO RECEIVER (BEHIND LEFT REAR INTERIOR TRIM PANEL) DK GRN WIRE DK GRN/WHT WIRE GROUND GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK INFOTMNT FUSE RADIO RADIO ANTENNA RED WIRE RED/WHT WIRE SERIAL DATA SERIAL DATA R AUD SIG (-) R AUD SIG (+) L AUD SIG (+) L AUD SIG (-) TAN/WHT WIRE WHT WIRE
