Compressor circuit, with auto a/c for Saturn Outlook I (2006-2010)
Compressor circuit, with auto a/c
33 53 21 37 57 HI SPD BUS - HI SPD BUS + LOW REF
A/C CLUTCH
A/C CMPRSR CLTCH RELAY
A/C COMPRESSOR CLUTCH (LOWER LEFT FRONT OF ENGINE)
A/C PRESSURE
A/C REFRIGERANT PRESSURE SENSOR (NEAR REAR OF A/C COMPRESSOR)
AC CLTCH FUSE
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
EMISSION 2 FUSE
ENGINE CONTROL MODULE (ECM) (LEFT FRONT CORNER OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ PWR/TRN RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOGIC HVAC CONTROL MODULE
ORG/BLK WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
