Saturn Outlook I (2006-2010) windshield wiper motor (left rear of Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper motor (left rear of, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper motor (left rear of (1 of 1)
1 2 3 4 5 6 HEATED WASH SW HEATED WASH IND
13 20 21 300 91 860 POWER MODE WINDSHIELD WPR LO WINDSHIELD WPR HI
14 15 WSH SENS WSH IND
2 1 GROUND HEAT FLUID
AIR BAG FUSE
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
ENGINE COMPT)
FRT/WSW FUSE
FRT/WSW RELAY
GMC/SATURN
GROUND WNDSHD WSR SW POWER MODE PNK WIRE
GRY WIRE
HEADLAMP SWITCH
HI LO
HI MIST
HOT AT ALL TIMES
HOT W/ IGN RELAY ENERGIZED
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
IGN II/III
INSTRUMENT PANEL CLUSTER (IPC)
LO OFF WASHER SWITCH INT
LOGIC
LT BLU WIRE
LT GRN WIRE
OFF
ORG/ WIRE
PARK
PNK WINDSHIELD WASHER SW WIRE
PNK WIRE
PPL
RED/WHT WIRE
RESERVOIR)
SER DATA
TAN WIRE
TAN/BLK WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
W/ HEATED WINDSHIELD WASHER NOZZLES W/O HEATED WINDSHIELD WASHER NOZZLES
WASHER FLUID LEVEL
WASHER SWITCH
WINDSHIELD WASH
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP (ON WASHER FLUID
WINDSHIELD WASHER SOLVENT HEATER (IF EQUIPPED) (LEFT REAR OF ENGINE COMPT)
WINDSHIELD WIPER MOTOR (LEFT REAR OF
WINDSHIELD WIPERS PARK
WIPER SWITCH MIST
WPR HI RELAY
WPR RELAY
WPR/ WSW FUSE HTD WASH FUSE
YEL WIRE
Go to component -> Front wiper/washer circuit -> WINDSHIELD WIPER MOTOR (LEFT REAR OF
