Saturn Outlook I (2006-2010) w/ rear audio control Wiring diagram
This page shows the only wiring diagram for the component.w/ rear audio control, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ rear audio control (1 of 1)
AUXILIARY BLOWER MOTOR CONTROL MODULE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
CARGO LAMP
CLOCK
CONSOLE FLOOD LAMP
COURTESY/ READING LAMPS
DATA LINK CONNECTOR
FRONT OVERHEAD CONSOLE COURTESY/ READING LAMPS
GMC
HARNESS)
HEADLAMP SWITCH
HORN SWITCH
INFLATABLE RESTRAINT FRONT PASSENGER PRESENCE SYSTEM (PPS) SENSOR
INFLATABLE RESTRAINT I/P MODULE INDICATOR
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INFLATABLE RESTRAINT VEHICLE ROLLOVER SENSOR
LEFT STEERING WHEEL CONTROL SWITCH
LEFT SUNSHADE
MANUAL A/C AUTOMATIC A/C
REAR OVERHEAD CONSOLE COURTESY/ READING LAMPS
REAR SEAT AUDIO (RSA) CONTROL
RIGHT REAR MARKER LAMP
RIGHT SUNSHADE
RIGHT TAIL LAMP
RIGHT TAIL/ STOP/ TURN SIGNAL LAMP
SATURN
SATURN BUICK
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
THEFT TURN SIGNAL/ DETERRENT MULTIFUNCTION MODULE SWITCH (TDM)
TRAILER CONNECTOR
W/ REAR AUDIO CONTROL
W/ SUNROOF
W/ SUNROOF, REAR SEAT ENTERTAINMENT
W/ SUNSHADE
W/O SUNROOF, REAR SEAT ENTERTAINMENT
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> W/ REAR AUDIO CONTROL
