Saturn Outlook I (2006-2010) w/ multi- directional passenger seat adjuster Wiring diagrams
This page contains all the electrical diagrams for the component. w/ multi- directional passenger seat adjuster, in which he is found in the car Saturn Outlook I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ multi- directional passenger seat adjuster (1 of 2)
BLK WIRE
DK BLU WIRE
DK GRN WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
LT GRN WIRE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT HORIZONTAL MOTOR (UNDER FRONT PASSENGER'S SEAT)
PASSENGER SEAT RECLINE MOTOR (IN FRONT PASSENGER'S SEAT BACK)
RED/WHT WIRE
RT/PWR/SEAT CIRCUIT BREAKER
RWD
TAN WIRE
W/ 4-WAY PASSENGER SEAT ADJUSTER
W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
Go to component -> Passenger power seat circuit -> W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
Wiring diagram w/ multi- directional passenger seat adjuster (2 of 2)
AUTOMATIC TRANSMISSION
AUXILIARY BLOWER MOTOR CONTROL MODULE
BATT 2 FUSE
BCK/UP/STOP FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
DRIVER HEATED SEAT CONTROL MODULE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SWITCH
FROM TRLR PWR FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 4)
HTD WASH FUSE
HTD/ SEAT FUSE PWR/ COLUMN CIRCUIT BREAKER
I/P FUSE BLOCK (BEHIND
L/GATE RELAY
LIFTGATE MODULE (LGM)
LT/PWR/ SEAT CIRCUIT BREAKER
LT/TRN/SIG FUSE
MEMORY SEAT MODULE (MSM)
OUTSIDE REARVIEW MIRROR SWITCH (IF EQUIPPED)
PASSENGER DOOR CONTROL MODULE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SWITCH
PDM FUSE
PWR L/GATE FUSE
PWR OUTLET FUSE
PWR/ MIR FUSE
RED WIRE
RIGHT END OF DASH)
RR APO FUSE
RR HVAC FUSE
RT/PWR/ SEAT CIRCUIT BREAKER
RT/TRN/SIG FUSE
RVC SNSR FUSE
S/ROOF/ SUNSHADE FUSE
STREEING WHEEL/COLUMN TILT/TELESCOPE SWITCH (IF EQUIPPED)
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
TCM FUSE
TO ACCESSORY AC/DC POWER CONTROL MODULE (DIAGRAM 4 OF 4)
TO FOG LAMP FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 3 OF 4)
TO REAR AUXILIARY POWER OUTLET (DIAGRAM 4 OF 4)
TRAILER BRAKE (BLUNT CUT)
TRLR BRK FUSE
W/ 4-WAY PASSENGER SEAT ADJUSTER
W/ EXPRESS POWER WINDOWS
W/ MANUAL LIFTGATE
W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
W/ POWER LIFTGATE
W/ POWER SLIDING SUNROOF
W/ POWER TILT, TELESCOPING
W/ TRAILER PROVISIONS
W/ WINDSHIELD HEATED WASHER NOZZLES
WHT WIRE
WINDSHIELD WASHER SOLVENT HEATER
Go to component -> Power distribution circuit (2 of 4) -> W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
