Saturn Outlook I (2006-2010) trlr brk fuse Wiring diagrams
This page contains all the electrical diagrams for the component. trlr brk fuse, in which he is found in the car Saturn Outlook I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
trlr brk fuse wiring diagram (1 of 2)
AUTOMATIC TRANSMISSION
AUXILIARY BLOWER MOTOR CONTROL MODULE
BATT 2 FUSE
BCK/UP/STOP FUSE
BLK WIRE
BODY CONTROL MODULE (BCM)
DRIVER HEATED SEAT CONTROL MODULE
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SWITCH
FROM TRLR PWR FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 4)
HTD WASH FUSE
HTD/ SEAT FUSE PWR/ COLUMN CIRCUIT BREAKER
I/P FUSE BLOCK (BEHIND
L/GATE RELAY
LIFTGATE MODULE (LGM)
LT/PWR/ SEAT CIRCUIT BREAKER
LT/TRN/SIG FUSE
MEMORY SEAT MODULE (MSM)
OUTSIDE REARVIEW MIRROR SWITCH (IF EQUIPPED)
PASSENGER DOOR CONTROL MODULE
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SWITCH
PDM FUSE
PWR L/GATE FUSE
PWR OUTLET FUSE
PWR/ MIR FUSE
RED WIRE
RIGHT END OF DASH)
RR APO FUSE
RR HVAC FUSE
RT/PWR/ SEAT CIRCUIT BREAKER
RT/TRN/SIG FUSE
RVC SNSR FUSE
S/ROOF/ SUNSHADE FUSE
STREEING WHEEL/COLUMN TILT/TELESCOPE SWITCH (IF EQUIPPED)
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
TCM FUSE
TO ACCESSORY AC/DC POWER CONTROL MODULE (DIAGRAM 4 OF 4)
TO FOG LAMP FUSE (UNDERHOOD FUSE BLOCK) (DIAGRAM 3 OF 4)
TO REAR AUXILIARY POWER OUTLET (DIAGRAM 4 OF 4)
TRAILER BRAKE (BLUNT CUT)
TRLR BRK FUSE
W/ 4-WAY PASSENGER SEAT ADJUSTER
W/ EXPRESS POWER WINDOWS
W/ MANUAL LIFTGATE
W/ MULTI- DIRECTIONAL PASSENGER SEAT ADJUSTER
W/ POWER LIFTGATE
W/ POWER SLIDING SUNROOF
W/ POWER TILT, TELESCOPING
W/ TRAILER PROVISIONS
W/ WINDSHIELD HEATED WASHER NOZZLES
WHT WIRE
WINDSHIELD WASHER SOLVENT HEATER
Go to component -> Power distribution circuit (2 of 4) -> TRLR BRK FUSE
trlr brk fuse wiring diagram (2 of 2)
13 12 LEFT TRAILER TURN SIG LAMP RIGHT TRAILER TURN SIG LAMP
BACKUP LAMP RELAY CONTROL
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
BRN WIRE
DK BLU WIRE
DK GRN WIRE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
I/P LAMP SPLY VOLT
LT GRN WIRE
LT TRLR STOP/TRN FUSE
LT TRLR STOP/TRN RELAY
ORG/ WIRE
PARK LAMP RELAY
RED WIRE
RED/BLK WIRE
RT TRLR STOP/TRN FUSE
RT TRLR STOP/TRN RELAY
STOP LAMP SUPPLY VOLTAGE
TRAILER CONNECTOR
TRAILER PROVISION (BLUNT CUT) (IF EQUIPPED)
TRLR BCK/UP FUSE
TRLR BCK/UP RELAY (IF EQUIPPED)
TRLR BRK FUSE
TRLR PRK LAMP FUSE
TRLR PWR FUSE (IF EQUIPPED)
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
YEL WIRE
Go to component -> Trailer tow circuit -> TRLR BRK FUSE
