Saturn Outlook I (2006-2010) right rear stop/turn lamp sply volt Wiring diagram
This page shows the only wiring diagram for the component.right rear stop/turn lamp sply volt, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right rear stop/turn lamp sply volt (1 of 1)
1 3 4 5 B+ B+ B+ RIGHT TURN SIG IND LAMP
15 16 19 LEFT TURN SIGNAL RIGHT TURN SIGNAL HAZARD SW SIG
AUTO
BCK/UP/STOP FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRN/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HAZARD SWITCH
HEADLAMP SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
LEFT REAR MARKER LAMP
LEFT TAIL/STOP, TURN SIGNAL LAMP
LOW REFERENCE
LOW SPD GMLAN SER DATA
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT/TRN/SIG FUSE
OFF
PARK HEAD
PARK LAMPS SPLY VOLT
RED WIRE
RED/WHT WIRE
RIGHT REAR MARKER LAMP
RIGHT REAR STOP/TURN LAMP SPLY VOLT
RIGHT TAIL/STOP, TURN SIGNAL LAMP
RT/TRN/SIG FUSE
SATURN
SATURN BUICK
STOP LAMP SPLY VOLTAGE
STOP LAMP SW SIG
TAN WIRE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> RIGHT REAR STOP/TURN LAMP SPLY VOLT
