Saturn Outlook I (2006-2010) ppl 12-volt reference Wiring diagram

22 8 9 CRUISE CNTRL IND GMLAN SER DATA BUS+ GMLAN SER DATA BUS- 2501 2500 COMPUTER DATA LINES SYSTEM 33 53 GLMAN SER DATA BUS- GLMAN SER DATA BUS+ 7 20 33 47 36 35 49 37 STOP LAMP SUP VOLT B+ ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL) AIR BAG FUSE APP SEN 1 SIG LOW REF APP SEN 2 SIG LOW REF PPL AUTOMATIC TRANSMISSION BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH) BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY) BRN WIRE COMPUTER DATA LINES SYSTEM CONTROL SOLENOID VALVE ASSEMBLY CRUISE CNTRL SW SIG CRUISE IND CRUISE SWITCH DK BLU WIRE DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ECM FUSE END OF DASH) ENGINE CONTROL MODULE (ECM) (LEFT FRONT CORNER OF ENGINE COMPT) GMLAN SERIAL DATA GND SENS SIG GRN/WHT WIRE GRY WIRE HOT AT ALL TIMES HOT W/ IGN RELAY ENERGIZED I/P FUSE BLOCK (BEHIND RIGHT INSTRUMENT PANEL CLUSTER (IPC) LEFT STEERING WHEEL CONTROL SWITCH ASSEMBLY LOGIC LT BLU WIRE LT GRN WIRE OUTPUT SPEED SENSOR PNK IGN WIRE PNK WIRE PPL PPL 12-VOLT REFERENCE RED/WHT WIRE RESET+ SET- SOUND SYSTEMS STOP LAMP SUP VOLT TAN WIRE TAN/BLK WIRE THROTTLE BODY (TOP REAR OF ENGINE) TP SEN 1 SIG LOW REF TP SEN 2 SIG TAC MOT CNTRL 2 TAC MOT CNTRL 1 GROUND TRANSMISSION CONTROL MODULE TRANSMISSIONS, SOUND SYSTEMS UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL) WHT WIRE WHT/BLK WIRE YEL WIRE
