Saturn Outlook I (2006-2010) left left high beam headlamp headlamp ballast Wiring diagram
This page shows the only wiring diagram for the component.left left high beam headlamp headlamp ballast, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left left high beam headlamp headlamp ballast (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM)
GMC
HARNESS)
INTAKE ENGINE MANIFOLD TUNING (IMT) CONTROL SOLENOID MODULE VALVE (ECM) BATTERY
LEFT ADAPTIVE FORWARD LIGHTING (AFL) MOTOR
LEFT DAYTIME RUNNING LAMP (DRL)
LEFT FRONT FOG LAMP
LEFT FRONT LOWER TURN SIGNAL LAMP
LEFT FRONT MARKER LAMP
LEFT FRONT UPPER TURN SIGNAL LAMP
LEFT HEADLAMP BALLAST
LEFT HIGH BEAM HEADLAMP
LEFT HIGH BEAM HEADLAMP SOLENOID
LEFT LEFT FRONT FRONT
LEFT LEFT HIGH BEAM HEADLAMP HEADLAMP BALLAST
LEFT LOW BEAM HEADLAMP
REAR WINDOW WASHER FLUID PUMP
RIGHT FRONT FOG LAMP
SATURN
SIGNAL HARNESS,
TRLR FUEL RIGHT REAR IGN DEFOG CRANK PUMP BCK/UP RELAY RELAY RELAY RELAY RELAY
W/ HID
W/ TRAILER PROVISIONS
W/ W/O HID HID HID
W/O
W/O HID
WHT WIRE
WINDSHIELD WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR
WIPER RELAY
Go to component -> Ground distribution circuit (1 of 5) -> LEFT LEFT HIGH BEAM HEADLAMP HEADLAMP BALLAST
