Saturn Outlook I (2006-2010) (in body harness, Wiring diagram
This page shows the only wiring diagram for the component.(in body harness,, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (in body harness, (1 of 1)
11 6 KEYPAD SIG SUPPLY VOLTAGE
3 2 KEYPAD GREEN LED
AMBIENT SENSOR MIRROR SIG
AUTOMATIC DAY/NIGHT MIRROR
AUTOMATIC DAY/NIGHT MIRROR OFF MIN
BACK-UP
BCK/UP/ STOP FUSE
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/LT GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRN/WHT WIRE
CALL
DK GRN/WHT WIRE
DRIVER OUTSIDE REARVIEW MIRROR (W/ MEMORY) (ON DRIVER'S DOOR)
EMERGENCY
GND BACK UP
GREEN
GRY WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
IGN
INSIDE REARVIEW MIRROR
KEYPAD RED LED WIRE
LOGIC
LOW REF
LT GRN WIRE
LT GRN/BLK WIRE
MAX
MIRROR DISPLAY (W/ COMPASS)
ONSTAR
ONSTAR BUTTON ASSEMBLY
PNK WIRE
POWER DISTRIBUTION SYSTEM
POWER TOPS SYSTEM
REAR LIGHT SENSOR
RED WIRE
RED/WHT WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> (IN BODY HARNESS,
