Saturn Outlook I (2006-2010) hi spd gmlan ser data bus- hi spd gmlan ser data bus- low reference Wiring diagram

ABS AIR BAG MTR FUSE FUSE ABS IND. ABS MTR FUSE BLK WIRE BLK/WHT WIRE BRAKE PRESSURE MODULATOR VALVE (BPMV) BRAKE VACUUM SEN SIG VEHICLE SPEED SIG LOW REFERENCE BRN WIRE BRN/WHT WIRE CAN BUS HIGH SERIAL DATA GROUND CAN HI CAN LO COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM ELECTRONIC POWER STEERING SYSTEM DK GRN WIRE DK GRN/WHT WIRE DRIVER INFORMATION CENTER (IPC) DISPLAY ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF ENGINE COMPT) ENGINE CONTROLS SYSTEM ELECTRONIC POWER GRY WIRE HI SPD GMLAN SER DATA BUS- HI SPD GMLAN SER DATA BUS- LOW REFERENCE HOT AT ALL TIMES HOT W/ IGN RELAY ENERGIZED I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) I/P SWITCH ASSEMBLY INSTRUMENT PANEL CLUSTER (IPC) LO REF LOGIC LT BLU WIRE LT GRN/BLK WIRE NCA WIRE ORG/ WIRE PNK IGN WIRE PNK WIRE PPL/WHT WIRE RED/BLK WIRE RED/WHT WIRE RF HIGH WSS RR HIGH WSS LR LOW WSS LF HIGH WSS RIGHT FRONT WHEEL SPEED SENSOR (WSS) (ON RIGHT FRONT HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (WSS) (ON RIGHT REAR HUB ASSEMBLY) RR LOW WSS 12 VOLT REFERENCE LR HIGH WSS LF LOW WSS COMMUNICATION ENABLE STEERING SYSTEM STEERING WHEEL SPEED POSITION SENSOR (TOP OF STEERING COLUMN) TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TCS ENBLE /DISABLE BUS- BUS+ LO SPD DT TRACTION CONTROL SWITCH UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL) VARIABLE EFFORT HIGH LOW REFERENCE VEH SPD WHT WIRE YAW RATE, LATERAL ACCELERATION SENSOR (UNDER FLOOR CONSOLE) YEL WIRE YEL/BLK WIRE
