Saturn Outlook I (2006-2010) emission 1 fuse even coils fuse Wiring diagram
This page shows the only wiring diagram for the component.emission 1 fuse even coils fuse, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram emission 1 fuse even coils fuse (1 of 1)
20 21 22 23 24 PPL
A/C CMPRSR CLUTCH RELAY
ACCELERATOR PEDAL POSITION (APP) SENSOR (ABOVE ACCELERATOR PEDAL)
AIR CONDITIONING SYSTEM COOLING FANS
APP SEN 1 SIG FTP SENS SIG APP SENS 2 SIG
BRN WIRE
BRN/WHT WIRE
CLUTCH RLY CTRL COOLING FAN RLY CTRL VENT SOLENOID CTRL
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ECM 1 FUSE ODD COILS FUSE ECM FUSE
EMISSION 1 FUSE EVEN COILS FUSE
EMISSION 2 FUSE
ENGINE CONTROL MODULE (ECM) (LEFT FRONT CORNER OF ENGINE COMPT)
FAN 1 RELAY
FAN 2 RELAY
FAN 3 RELAY
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGN RELAY ENERGIZED
IGN VOLT IGN VOLT B+ PNK WIRE
LOW REF
LOW REF LOW REF PPL
LT BLU WIRE
MIL CTRL FUEL PUMP RLY
ORG/BLU WIRE
PCM IGN FUSE
PNK WIRE
PNK/BLK WIRE
POWERTRAIN RLY
PPL
PPL FUEL LEVEL SENS SIG
PWR/TRN RELAY
RED/WHT WIRE
STARTER RLY COIL CTRL
STARTING/ CHARGING SYSTEM
STOP LP SPLY VOLT
SYSTEM
TAC MOTOR CTRL 1 TAC MOTOR CTRL 2 IGN VOLT CAM PHASER 2 CTRL CAM PHASER 4 CTRL
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
THROTTLE BODY (TOP REAR OF ENGINE)
UNDERHOOD FUSE BLOCK
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.6l vin 7 (1 of 5) -> EMISSION 1 FUSE EVEN COILS FUSE
