Saturn Outlook I (2006-2010) data bus- ign volt data bus- ign volt stop lp sw Wiring diagram
This page shows the only wiring diagram for the component.data bus- ign volt data bus- ign volt stop lp sw, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data bus- ign volt data bus- ign volt stop lp sw (1 of 1)
2501 1339 2501 5985 17 COMPUTER DATA LINES SYSTEM
AUTOMATIC TRANSMISSION
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (UNDER LEFT SIDE OF DASH)
BRN WIRE
COMPUTER
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
CRUISE CONTROL, SOUND, NAVIGATION SYSTEMS PPL
DATA BUS- IGN VOLT DATA BUS- IGN VOLT STOP LP SW
DATA LINES
DK BLU WIRE
ENGINE CONTROL MODULE (ECM) (LEFT FRONT CORNER OF ENGINE COMPT)
GMLAN BUS-
GRN WIRE
GROUND B+
HOT AT ALL TIMES
HOT AT ALL TIMES IGNITION SWITCH
HOT W/ IGN RELAY ENERGIZED
I/P SWITCH ASSEMBLY TOW/ HAUL SWITCH
IGN
INPUT SPEED SENSOR (ISS)
INTERNAL MODE SWITCH
ISS LOW
ISS/OSS HIGH
LT BLU WIRE
OFF
ORG/BLK WIRE
OUTPUT SPEED SENSOR (OSS)
PARK/NEUTRAL
PNK WIRE
PPL
RED WIRE
RED/WHT WIRE
RUN WIRE
STOP LP SPLY VOLT
SYSTEM
TAN WIRE
TAN/BLK WIRE
TAP UP/TAP DOWN
TCM FUSE
TOW/HAUL SW SIG
TRANS FUSE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION RANGE SIG A
TRANSMISSION RANGE SIG B
TRANSMISSION RANGE SIG C
TRANSMISSION RANGE SIG P
UNDERHOOD FUSE BLOCK (ABOVE RIGHT FRONT WHEELWELL)
WHT WIRE
YEL WIRE
Go to component -> A/t circuit (2 of 2) -> DATA BUS- IGN VOLT DATA BUS- IGN VOLT STOP LP SW
