Saturn Outlook I (2006-2010) computer data lines serial data system Wiring diagram
This page shows the only wiring diagram for the component.computer data lines serial data system, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines serial data system (1 of 1)
AWD FUSE (ABOVE RIGHT FRONT WHEELWELL)
BLK WIRE
CASE FLUID TEMP CASE ACTUATOR LOW LOW REFERENCE CASE ACTUATOR HI
COMMUNICATION ENABLE B+
COMPUTER DATA LINES SERIAL DATA SYSTEM
DK GRN WIRE
DRIVER INFORMATION CENTER (DIC) DISPLAY
GMLAN DATA BUS- GMLAN DATA BUS+
GROUND
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LT BLU WIRE
REAR DIFFERENTIAL CLUTCH CONTROL MODULE
REAR WHEEL DRIVE MODULE CLUTCH (AT REAR DIFFERENTIAL)
RED/WHT WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK
YEL WIRE
Go to component -> Rear differential lock circuit -> COMPUTER DATA LINES SERIAL DATA SYSTEM
