Saturn Outlook I (2006-2010) 8 7 2098 2110 tilt forward mtr tilt reverse mtr Wiring diagram

14 5 SEAT SW EXIT SIG 2 1 B+ GND 2112 2111 PNK WIRE 7 8 TILT MTR CTRL DN TILT REVERSE UP 8 7 2098 2110 TILT FORWARD MTR TILT REVERSE MTR BCK/UP/STOP FUSE BLK WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER MEMORY SEAT ADJUSTER SWITCH DRIVER'S MEMORY SEAT CIRCUIT EXIT GMLAN GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES I/P FUSE BLOCK (BEHIND RIGHT END OF DASH) INTERIOR LIGHTS SYSTEM 3 2 LOGIC LOW REFERENCE MEMORY SEAT MODULE (UNDER DRIVER'S SEAT) ORG/ WIRE PNK WIRE PWR COLUMN CIRCUIT BREAKER RED/WHT WIRE RWD DN FWD SERIAL DATA STEERING COLUMN TILT/TELESCOPE ACTUATOR STEERING WHEEL/ COLUMN TILT/ TELESCOPE SWITCH TAN WIRE TELESCOPE SENS SIG TILT SENS SIG WHT WIRE YEL WIRE
