Saturn Outlook I (2006-2010) 2112 2111 pnk Wiring diagram
This page shows the only wiring diagram for the component.2112 2111 pnk, which is found in the car Saturn Outlook I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 2112 2111 pnk (1 of 1)
14 5 SEAT SW EXIT SIG
2 1 B+ GND
2112 2111 PNK WIRE
7 8 TILT MTR CTRL DN TILT REVERSE UP
8 7 2098 2110 TILT FORWARD MTR TILT REVERSE MTR
BCK/UP/STOP FUSE
BLK WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DRIVER MEMORY SEAT ADJUSTER SWITCH
DRIVER'S MEMORY SEAT CIRCUIT
EXIT
GMLAN
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
I/P FUSE BLOCK (BEHIND RIGHT END OF DASH)
INTERIOR LIGHTS SYSTEM 3 2
LOGIC
LOW REFERENCE
MEMORY SEAT MODULE (UNDER DRIVER'S SEAT)
ORG/ WIRE
PNK WIRE
PWR COLUMN CIRCUIT BREAKER
RED/WHT WIRE
RWD DN FWD
SERIAL DATA
STEERING COLUMN TILT/TELESCOPE ACTUATOR
STEERING WHEEL/ COLUMN TILT/ TELESCOPE SWITCH
TAN WIRE
TELESCOPE SENS SIG
TILT SENS SIG
WHT WIRE
YEL WIRE
Go to component -> Memory power tilt & power telescopic circuit -> 2112 2111 PNK WIRE
