Electronic power steering circuit for Saturn ION I (2003-2007)
Electronic power steering circuit
B(+)
BLK WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM PNK WIRE
ELECTRIC POWER STEERING (EPS) MOTOR
EPS FUSE
EPS FUSE 43
GROUND
HOT AT ALL TIMES
HOT IN RUN OR START
IGNITION 1 CLASS 2 SERIAL DATA
LOGIC
PNK W/ CRUISE CONTROL WIRE
PNK WIRE
POWER STEERING CONTROL MODULE (PSCM)
RED WIRE
SIDE OF ENGINE COMPARTMENT)
STEERING COLUMN ASSEMBLY
TORQUE SENSOR
UNDERHOOD FUSE BLOCK (AT LEFT REAR
VIO WIRE
