Saturn ION I (2003-2007) w/o power windows, power mirrors Wiring diagram
This page shows the only wiring diagram for the component.w/o power windows, power mirrors, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o power windows, power mirrors (1 of 1)
2.2L
A/T
A/T SHIFT LOCK SOLENOID
AUTOMATIC TRANSMISSION (A/T) SHIFT INDICATOR LAMP
BARE
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR
BODY CONTROL MODULE (BCM)
BRAKE FLUID LEVEL SWITCH
COUPE
DATA LINK CONNECTOR (DLC)
DRIVER DOOR JAMB SWITCH
DRIVER DOOR LOCK SWITCH DRIVER WINDOW SWITCH
DRIVER WINDOW SWITCH
FOG LAMP SWITCH
FRONT AUXILIARY POWER OUTLET
FRONT PASSENGER DOOR JAMB SWITCH
FRONT PASSENGER DOOR LOCK SWITCH
FUEL PUMP (FP)
FUEL PUMP RELAY
FUEL PUMP, SENDER ASSEMBLY
HAZARD SWITCH
HEADLAMP RELAY
HVAC CONTROL ASSEMBLY
IGNITION LOCK CYLINDER CONTROL SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
INSTRUMENT PANEL CLUSTER (IPC)
LEFT SEAT BELT SWITCH
LOGIC
NCA WIRE
OUTSIDE REARVIEW MIRROR SWITCH
RADIO
REAR AUXILIARY POWER OUTLET
SEDAN
TRACTION CONTROL SWITCH
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ POWER WINDOWS, POWER MIRRORS
W/O POWER WINDOWS, POWER MIRRORS
Go to component -> Ground distribution circuit (2 of 3) -> W/O POWER WINDOWS, POWER MIRRORS
