Saturn ION I (2003-2007) wiper 2 relay 33 Wiring diagram
This page shows the only wiring diagram for the component.wiper 2 relay 33, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper 2 relay 33 (1 of 1)
BLK WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
DK GRN WIRE
GRY WIRE
HIGH LOW
HIGH LOW INT
HOT IN ACC OR RUN
LOGIC
LT GRN WIRE
MIST OFF
MIST OFF INT
PPL
RED WIRE
UNDERHOOD FUSE BLOCK
WASH
WINDSHIELD WASHER FLUID PUMP (ON BOTTOM OF WASHER FLUID RESERVOIR)
WINDSHIELD WASHER PUMP CONTROL
WINDSHIELD WIPER MOTOR PARK SWITCH SIGNAL
WINDSHIELD WIPER SWITCH SIGNAL 1
WINDSHIELD WIPER SWITCH SIGNAL 2
WINDSHIELD WIPER/WASHER SWITCH
WIPER 1 RELAY 32
WIPER 2 RELAY 33
WIPER DIODE 37
WIPER FUSE 19
WIPER SW FUSE
YEL WIRE
Go to component -> Wiper/washer circuit -> WIPER 2 RELAY 33
