Saturn ION I (2003-2007) low speed gm lan serial data Wiring diagrams
This page contains all the electrical diagrams for the component. low speed gm lan serial data, in which he is found in the car Saturn ION I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram low speed gm lan serial data (1 of 2)
2.2L
AUTOMATIC TRANSMISSION
BCM CLASS 2 SERIAL DATA
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
CLASS 2 SERIAL DATA
DATA LINK CONNECTOR (DLC) (UNDER LOWER LEFT SIDE OF DASH)
DATA LINK CONNECTOR (DLC) BREAKOUT)
DK GRN WIRE
EBCM CLASS 2 SERIAL DATA
EPS CLASS 2 SERIAL DATA
FROM DATA LINK CONNECTOR (DLC) BREAKOUT)
HIGH SPEED GM LAN SERIAL DATA BUS +
HIGH SPEED GM LAN SERIAL DATA BUS + HIGH SPEED GM LAN SERIAL DATA BUS -
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
IPC CLASS 2 SERIAL DATA
LIGHTER FUSE
LOGIC
LOGIC POWER STEERING CONTROL MODULE (PSCM)
LOGIC RADIO 2.0L 2.2L
LOW SPEED GM LAN SERIAL DATA
MANUAL TRANSMISSION
MODULE (PCM)
ORG/ WIRE
PPL
SDM CLASS 2 SERIAL DATA
STEERING COLUMN ASSEMBLY
TAN WIRE
TAN/WHT WIRE
VCIM CLASS 2 SERIAL DATA
WHT/ BLK WIRE
Go to component -> Computer data lines circuit -> LOW SPEED GM LAN SERIAL DATA
Wiring diagram low speed gm lan serial data (2 of 2)
AUDIO CMMON
BARE
BATTERY VOLT
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
BRN/WHT WIRE
COAX ANT IN (SAT)
COAX ANT IN (TERR) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
DK GRN WIRE
DK GRN/WHT WIRE
GROUND AUDIO COMMON DRAIN WIRE
HOT AT ALL TIMES
L AUDIO SIG (+) R AUDIO SIG (+)
LOW SPEED GM LAN SERIAL DATA
ONSTAR FUSE
ORG/ WIRE
RADIO
SERIAL DATA
W/ ONSTAR
Go to component -> Satellite radio circuit -> LOW SPEED GM LAN SERIAL DATA
