Saturn ION I (2003-2007) left steering wheel controls Wiring diagram
This page shows the only wiring diagram for the component.left steering wheel controls, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left steering wheel controls (1 of 1)
2.0L 2.2L
ACCELERATOR PEDAL POSITION (APP) SENSOR (BELOW LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
BRN WIRE
BRN/WHT WIRE
CLUTCH PEDAL POSITION (CPP) SWITCH (M/T) (BELOW LEFT SIDE OF DASH)
CLUTCH/BRAKE FUSE
CPP SW SIG
CRUISE CONTROL ON IND
DK BLU WIRE
DK GRN WIRE
ECM CLASS 2 SERIAL DATA
EPS FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
INSTRUMENT PANEL CLUSTER (IPC)
IPC CLASS 2 SERIAL DATA
LEFT STEERING WHEEL CONTROLS
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
MESSAGE CENTER
ORG/ WIRE
PNK WIRE
PPL
RESUME/ ACCEL
RIGHT STEERING WHEEL CONTROLS 2.0L 2.2L
SET/ COAST
SET/COAST RESUME/ ACCELERATE SIGNAL
STOP FUSE
STOP LAMP SW SIG
TAN WIRE
TCC BRAKE SW/CRUISE
UNDERHOOD FUSE BLOCK (AT LEFT REAR SIDE OF ENGINE COMPT)
UPPER STOP LAMP SWITCH
VEHICLE SPEED SENSOR (VSS) (M/T: AT REAR OF ENGINE, ON TRANSAXLE)
VSS HIGH
VSS LOW
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit -> LEFT STEERING WHEEL CONTROLS
