Saturn ION I (2003-2007) headlamps off signal low beam relay control Wiring diagram
This page shows the only wiring diagram for the component.headlamps off signal low beam relay control, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram headlamps off signal low beam relay control (1 of 1)
AMBIENT LIGHT SENSOR (2.2L, W/ AUTO LAMPS) (ON TOP LEFT SIDE OF DASH)
B+ VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
CLASS 2 SERIAL DATA 2
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
COUPE
DIMMER SWITCH
DK BLU WIRE
EMERGENCY BRAKE)
FOG LAMP FUSE 17
FOG LAMP IND
FOG LAMP RELAY 26
FOG LAMP RELAY CTRL
FOG LAMP SWITCH
FOG LAMP SWITCH SIGNAL
GRY WIRE
HEAD PARK AUTO OFF
HEADLAMP SWITCH
HEADLAMPS OFF SIGNAL LOW BEAM RELAY CONTROL
HIGH BEAM IND
HIGH BEAM SIG
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER
IPC CLASS 2 SERIAL DATA
LEFT FRONT FOG LAMP
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT HEAD- LAMP
LEFT TURN LAMP SUPPLY
LH HDLP FUSE 18
LIGHT SENSOR LOW REF
LIGHT SENSOR SIGNAL
LOGIC
LOW BEAM SIG
LT BLU WIRE
LT GRN/BLK WIRE
ORG/ WIRE
PARK BARAKE SWITCH SIGNAL
PARK BRAKE SWITCH (ATTACHED TO
PNK WIRE
PNK/WHT WIRE
PPL
PPL/WHT WIRE
RH HDLP FUSE 4
RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT HEAD- LAMP
RIGHT TURN LAMP SUPPLY
SEDAN
SEDAN, COUPE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK (AT LEFT REAR SIDE OF ENGINE COMPT)
VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit -> HEADLAMPS OFF SIGNAL LOW BEAM RELAY CONTROL
