Saturn ION I (2003-2007) driver door jamb switch signal Wiring diagrams

2.2L 2.0L 10 33 AJAR SWITCH B(+) BCM ELECT FUSE BCM PWR FUSE BLK WIRE BODY CONTROL MODULE BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH) CLUSTER FUSE DASH FUSE DK GRN WIRE DRIVER DOOR JAMB SWITCH (LEFT FRONT OF DASH, ON OUTER TRIM COVER) DRIVER DOOR JAMB SWITCH SIGNAL ECM CLASS 2 SERIAL DATA ENGINE CONTROLS SYSTEM FRONT PASSENGER DOOR JAMB SWITCH (RIGHT FRONT OF DASH, ON OUTER TRIM COVER) FUEL INJECTOR CONTROL GRY WIRE HORN RELAY CTRL HORNS SYSTEM HOT AT ALL TIMES IGNITION SWITCH INSTRUMENT PANEL CLUSTER LEFT REAR DOOR JAMB SWITCH (SEDAN) (NEAR DRIVER SEAT BELT) LOCK OFF LOGIC LOGIC B+ LT BLU WIRE LT GRN WIRE NCA WIRE OFF/ RUN/ CRANK VOLT BCM CLASS 2 SERIAL DATA ORG/ WIRE PASSENGER DOOR JAMB SWITCH SIGNAL PNK WIRE PPL PPL 2.0L 2.2L REAR COMPARTMENT LID LATCH (IN REAR COMPARTMENT LID) REF RIGHT REAR DOOR JAMB SWITCH (SEDAN) RUN WIRE SECURITY INDICATOR CONTROL TRUNK AJAR SWITCH SIGNAL TURN/ HAZARD SWITCH POWER WHT WIRE

B(+) BCM ELECT FUSE BCM PWR FUSE BLK WIRE BODY CONTROL MODULE (BCM) BODY CONTROL MODULE (BCM) (AT LOWER COUPE COURTESY LAMP LOW CONTROL COURTESY/ READING LAMP (W/ DUAL READING LAMP) DASH FUSE DK GRN WIRE DOME LAMP DRIVER DOOR JAMB SWITCH (LEFT FRONT OF DASH, ON OUTER TRIM COVER) DRIVER DOOR JAMB SWITCH SIGNAL FROM LEFT REAR SPEAKER BREAKOUT) FRONT PASSENGER DOOR JAMB SWITCH (RIGHT FRONT OF DASH, ON OUTER TRIM COVER) GROUND HOT AT ALL TIMES INADVERTENT POWER LEFT REAR DOOR JAMB SWITCH (SEDAN) LOGIC (AT LOWER CENTER OF DASH) LT BLU WIRE LT GRN WIRE MAP LIGHTS NCA WIRE OFF ON DOOR ORG/ WIRE PASSENGER DOOR JAMB SWITCH SIGNAL REAR AJAR SWITCH COMPARTMENT LID RELEASE ACTUATOR REAR COMPARTMENT COURTESY LAMP RIGHT REAR DOOR JAMB SWITCH (SEDAN) SEDAN TRUNK, TAILGATE, FUEL DOORS SYSTEM W/ REMOTE ENTRY W/O REMOTE ENTRY WHT WIRE
