Saturn ION I (2003-2007) cooling fan relay control Wiring diagrams
This page contains all the electrical diagrams for the component. cooling fan relay control, in which he is found in the car Saturn ION I (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
cooling fan relay control wiring diagram (1 of 2)
BLK WIRE
COOLING FAN 1 (ATTACHED TO LEFT SIDE OF RADIATOR)
COOLING FAN 1 FUSE 45
COOLING FAN 1 RELAY 30
COOLING FAN 2 (ATTACHED TO RIGHT SIDE OF RADIATOR)
COOLING FAN 2 FUSE 44
COOLING FAN RELAY CONTROL
COOLING FAN S/P RELAY CTRL
DK BLU WIRE
DK GRN WIRE
ECT SENSOR SIG
GRY WIRE
HOT AT ALL TIMES
LOW REF
LT BLU WIRE
RED WIRE
UNDERHOOD FUSE BLOCK
WHT WIRE
YEL WIRE
Go to component -> 2.0l vin p, cooling fan circuit -> COOLING FAN RELAY CONTROL
cooling fan relay control wiring diagram (2 of 2)
61 50 2761 410 LOW REF ECT SENSOR SIG
BLK WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
CLASS 2 (BCM)
CLASS 2 (BCM) IGN IGN
CLASS 2 SERIAL DATA
COOLANT LEVEL SWITCH (ATTACHED TO OVER FLOW CONTAINER)
COOLING FAN (AT FRONT OF ENGINE COMPARTMENT, ATTACHED TO RADIATOR)
COOLING FAN FUSE 45
COOLING FAN RELAY 30
COOLING FAN RELAY CONTROL
DK GRN WIRE
EMISS FUSE 10
ENGINE CONTROL MODULE (ECM) (AT LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE GAUGE
HOT AT ALL TIMES
HOT W/ POWERTRAIN RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW COOLANT LEVEL IND SIG
LT BLU WIRE
MESSAGE CENTER
PNK WIRE
PPL
PPL CLASS 2 SERIAL DATA
UNDERHOOD FUSE BLOCK (AT LEFT REAR SIDE OF ENGINE COMPT)
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.2l vin f, cooling fan circuit -> COOLING FAN RELAY CONTROL
