Saturn ION I (2003-2007) automatic day/ night mirror sig Wiring diagram
This page shows the only wiring diagram for the component.automatic day/ night mirror sig, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic day/ night mirror sig (1 of 1)
ACC VOLT
AMBIENT AIR TEMP SENS SIG
AMBIENT AIR TEMPERATURE SENSOR (AT LEFT FRONT OF VEHICLE, BEHIND GRILL)
AMBIENT LIGHT SENSOR
AUTOMATIC DAY-NIGHT MIRROR ELEMENT
AUTOMATIC DAY/ NIGHT MIRROR LOW REF
AUTOMATIC DAY/ NIGHT MIRROR SIG
BACKUP LAMPS SUPPLY VOLT
BLK WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
BRN/WHT WIRE
CELLULAR
DK GRN/WHT WIRE
GROUND
GRY WIRE
GRY/BLK WIRE
HEADLIGHT SENSOR
HOT AT ACC OR RUN
INSIDE REARVIEW MIRROR
KEYPAD
KEYPAD GREEN LED
KEYPAD SIGNAL
KEYPAD SUPPLY
LOGIC
LOW REF
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
POWER TOPS SYSTEM
RED LED WIRE
SUNROOF FUSE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> AUTOMATIC DAY/ NIGHT MIRROR SIG
