Saturn ION I (2003-2007) auto park headlamp switch wiring diagram
This page shows the only wiring diagram for the component.auto park headlamp switch, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
auto park headlamp switch wiring diagram (1 of 1)
ALC/ PARK RELAY
ANTI-LOCK BRAKES SYSTEM
AUTO PARK HEADLAMP SWITCH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (AT LOWER CENTER OF DASH)
BRN WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL) (6 BULBS)
COUPE, SEDAN
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS, TRANSMISSIONS SYSTEM
GRY WIRE
HAZARD SWITCH
HEAD
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT BACKUP LAMP
LEFT TAIL/ STOP LAMP
LEFT TAIL/ TURN SIGNAL LAMP
LEFT TURN SIGNAL IND
LEFT TURN SIGNAL INPUT
LEFT TURN SIGNAL LAMPS SUPPLY VOLT
LICENSE LAMP
LOGIC
LT BLU WIRE
OF DASH, ATTACHED TO BRAKE PEDAL BRACKET)
OFF
ORG/ WIRE
PARK FUSE
PARK LAMP RELAY CTRL
PARK LAMP SUPPLY VOLT
PREMIUM
RIGHT BACKUP LAMP
RIGHT FRONT MARKER LAMP (COUPE) LEFT FRONT MARKER LAMP (COUPE)
RIGHT LEFT
RIGHT TAIL/ STOP LAMP
RIGHT TAIL/ TURN SIGNAL LAMP
RIGHT TURN SIGNAL IND
RIGHT TURN SIGNAL INPUT
RIGHT TURN SIGNAL LAMPS SUPPLY VOLT
SEDAN, COUPE
STOP FUSE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
TURN SWITCH
TURN/HAZ SWITCH SUPPLY VOLT
UNDERHOOD FUSE BLOCK (AT LEFT REAR SIDE OF ENGINE COMPT)
UPPER STOP LAMP SWITCH (BELOW LEFT SIDE
YEL WIRE
Go to component -> Exterior lamps circuit -> AUTO PARK HEADLAMP SWITCH
