Saturn ION I (2003-2007) a/c diode 35 wiper 1 relay 32 Wiring diagram
This page shows the only wiring diagram for the component.a/c diode 35 wiper 1 relay 32, which is found in the car Saturn ION I (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c diode 35 wiper 1 relay 32 (1 of 1)
A/C COMPRESSOR CLUTCH
A/C DIODE 35 WIPER 1 RELAY 32
AUDIO AMPLIFIER
BATTERY
BLK WIRE
BLK/WHT WIRE
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
COUPE
COUPE, SEDAN
DIGITAL RADIO RECEIVER
DOME LAMP
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
FOG LAMP RELAY 26
HORN
LEFT BACKUP LAMP
LEFT FRONT FOG LAMP LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT TAIL/ STOP LAMP
LEFT TAIL/ TURN SIGNAL LAMP
MANUAL A/C
ONSTAR W/ S-BAND ONSTAR W/O S-BAND
REAR DEFOG RELAY 34 RUN/CRANK RELAY 28
RIGHT FRONT FOG LAMP RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT FRONT MARKER LAMP LEFT FRONT MARKER LAMP
S-BAND W/ ONSTAR S-BAND W/O ONSTAR
STEERING COLUMN ASSEMBLY POWER STEERING CONTROL MODULE (PSCM)
UNDERHOOD FUSE BLOCK (AT LEFT REAR SIDE OF ENGINE COMPARTMENT)
VEHICLE COMMUNICATION INTERFACE MODULE (VCIM)
W/ ABS
W/ PREMIUM SOUND
W/O PREMIUM SOUND
WHT WIRE
WINDSHIELD WASHER FLUID PUMP
WINDSHIELD WIPER MOTOR ASSEMBLY
WIPER 2 RELAY 32
Go to component -> Ground distribution circuit (1 of 3) -> A/C DIODE 35 WIPER 1 RELAY 32
