Anti-lock brakes circuit, hybrid without traction control for Saturn Aura I (2006-2010)

Anti-lock brakes circuit, hybrid without traction control (1 of 2)

Aura Saturn I (2006-2010): Anti-lock brakes circuit, hybrid without traction control (1 of 2)

Get access

ABS FUSE 15 ABS FUSE 24 BATT POSITIVE VOLT BATT POSITIVE VOLT IGN 1 VOLT BLK WIRE BLU WIRE BRAKE PRESSURE MODULATOR VALVE (BPMV) BRN WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE GND GND GRN WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ RUN/ CRANK RELAY ENERGIZED LAT ACCEL SIG LOW REF REF LT BLU WIRE LT GRN WIRE LT LT ORG/ WIRE ORG/BLK WIRE PNK WIRE POSITION POSITION SIG A REF SIG B VOLT PPL RED WIRE RED/BLK WIRE SENS SIG 2 STEERING WHEEL POSITION SENSOR (UNDER DASH, AT BASE OF STEERING COLUMN) TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY) WHT WIRE YAW RATE SENS SIG YAW, LATERAL ACCELEROMETER SENSOR (UNDER CENTER CONSOLE) YEL WIRE

Anti-lock brakes circuit, hybrid without traction control (2 of 2)

Aura Saturn I (2006-2010): Anti-lock brakes circuit, hybrid without traction control (2 of 2)

Get access

ABS IND. BATT POSITIVE VOLT BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH) BRAKE FLUID LEVEL SWITCH (UNDER CENTER BRAKE FLUID RESERVOIR) BRAKE PEDAL POSITION SENSOR (RIGHT SIDE BRAKE PEDAL BRACKET) BRK FLUID LVL SENS SIG BRN WIRE CLUSTER/ THEFT FUSE COMPUTER DATA LINES SYSTEM DK GRN WIRE HIGH SPEED GMLAN SERIAL DATA BUS (+) BPP SENS SIG HIGH SPEED GMLAN SERIAL DATA BUS + HOT AT ALL TIMES LO SPD GMLAN SERIAL DATA LOGIC BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH) LOGIC INSTRUMENT PANEL CLUSTER (IPC) LOW REF ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE WHT WIRE YEL WIRE
