Compressor circuit, with manual a/c for Saturn Aura I (2006-2010)
Compressor circuit, with manual a/c
12 34 13 27 28 57 37 21 53 33 25 65 8 43 44 SENS SIG
3.5L 3.6L, 2.4L (VIN 5) 2.4L (VIN B)
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
A/C COMPRESSOR CLUTCH (LOWER LEFT, FRONT OF ENGINE, PART OF A/C COMPRESSOR)
A/C REQ SIG
A/C REQUEST IND
A/C REQUEST SWITCH
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
CLU RLY CTRL
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
DK GRN/WHT WIRE
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA (+)
HOT AT ALL TIMES
HOT W/ PWR/TRN RELAY ENERGIZED
HVAC CONTROL MODULE
LOGIC
LOW REF HIGH SPD GMLAN HIGH SPD GMLAN
LOW SPEED GMLAN SERIAL DATA
MODE SWITCH
ORG/BLK WIRE
TAN WIRE
TAN/BLK WIRE
TEMPERATURE CONTROL SWITCH
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
