Saturn Aura I (2006-2010) vacuum sens sig app sensor 1 press sens sig app sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.vacuum sens sig app sensor 1 press sens sig app sensor 2, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vacuum sens sig app sensor 1 press sens sig app sensor 2 (1 of 1)
13 7 8 11 PNK WIRE
1809 1161 890 1162 ANTI-LOCK BRAKES SYSTEM
459 473 1310 AIR CONDITIONING SYSTEM COOLING FANS SYSTEM
6258 6257 1164 705 1274 1271 1272 ANTI-LOCK BRAKES SYSTEM
ACC VOLT IGN 1 BAT PNK WIRE
ACC VOLTAGE
ACCELERATOR PEDAL POSITION (APP) SENSOR (ACCELERATOR PEDAL BRACKET)
APP APP SENSOR 2 SENSOR 1
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CLUTCH RLY CTRL FAN RLY CTRL EVAP SOL CTRL
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
DRIVER INFORMATION CENTER (DIC)
ECM FUSE 13
ECM IGN FUSE 16
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, BEHIND BATTERY)
FUEL TANK PRESSURE (FTP) SENSOR (TOP OF FUEL PUMP, SENDER ASSEMBLY)
GRY WIRE
HOT AT ALL TIMES
IGN 1 VOLT GMLAN DATA GMLAN DATA IGN
IGN 1 VOLTAGE
IGNITION SWITCH
INSTRUMENT PANEL CLUSTER (IPC)
LOGIC
LOW REF
LOW REF LOW REF PPL
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MALFUNC- TION INDICATOR LAMP
MIL CTRL F PMP RLY CTRL
OFF
ORG/BLK WIRE
PNK WIRE
PPL
PPL FUEL LEVEL SENS
PPL/WHT WIRE
RED/WHT WIRE
RLY COIL CTRL
RLY CTRL
RUN WIRE
RUN/ CRANK RELAY 32
STARTING/CHARGING SYSTEM
STP LMP SW SIG
TAN WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
VACUUM SENS SIG APP SENSOR 1 PRESS SENS SIG APP SENSOR 2
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 2.4l vin 5, engine controls circuit (1 of 4) -> VACUUM SENS SIG APP SENSOR 1 PRESS SENS SIG APP SENSOR 2
