Saturn Aura I (2006-2010) to back-up lamps fuse 17 wiring diagram
This page shows the only wiring diagram for the component.to back-up lamps fuse 17, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
to back-up lamps fuse 17 wiring diagram (1 of 1)
3.5L/3.6L
32 10 (4 SPEED A/T) (6 SPEED A/T)
ABS FUSE 24
AUDIO AMP FUSE 13
AUDIO AMPLIFIER
B/U LP RELAY 33
BATTERY
BCK/UP LAMPS FUSE 17
BLK WIRE
BLU WIRE
CIG/AUX FUSE 20
CIGAR LIGHTER
CONSOLE AUXILIARY POWER OUTLET
DIGITAL RADIO RECEIVER (IF EQUIPPED)
DRIVER HEATED SEAT CONTROL MODULE
DRL FUSE 46
DRL RELAY 48
ECM FUSE 13 (2.4L (VIN 5), 3.6L)
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
ENGINE CONTROL MODULE (ECM)
EPS FUSE 41
FROM HTD SEAT FUSE 14 (DIAGRAM 1 OF 5)
FUSIBLE LINK (12 GA-
GARAGE DOOR OPENER (GDO) (IF EQUIPPED)
GENERATOR
HTD SEAT FUSE 14
PASSENGER HEATED SEAT CONTROL MODULE
POWER STEERING CONTROL MODULE
R/ WDO DEFOG RELAY 26
RBEC 1 FUSE 22
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RKE/XM S/ROOF FUSE 10 FUSE 16
STARTER GENERATOR CONTROL MODULE (SGCM)
STARTER MOTOR
SUNROOF CONTROL MODULE (IF EQUIPPED)
TCM FUSE 42
TO BACK-UP LAMPS FUSE 17
TO EMISSION 2 FUSE 5 (DIAGRAM 4 OF 5)
TO IBCM 2 FUSE 25 (DIAGRAM 2 OF 5)
TRANSMISSION CONTROL MODULE (TCM)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
W/ FRONT HEATED SEATS
WHT WIRE
Go to component -> Power distribution circuit (1 of 5) -> TO BACK-UP LAMPS FUSE 17
