Saturn Aura I (2006-2010) side of engine compt, front of battery) wiring diagram
This page shows the only wiring diagram for the component.side of engine compt, front of battery), which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
side of engine compt, front of battery) wiring diagram (1 of 1)
2.4L (VIN B) 2.4L (VIN 5) 3.5L 3.6L
2.4L (VINB), 2.4L (VIN 5)
3.6L
50 34 41 OIL PRES SENS SIG
53 33 28 27 53 33 43 44 SERIAL DATA + SERIAL DATA -
9 44 31 16 9 44 LOW REF FUEL LVL SENS SIG
BLK WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE OIL PRESSURE (EOP) SWITCH (3.6L) (LOWER FRONT, LEFT SIDE OF ENGINE)
ENGINE OIL PRESSURE (EOP) SWITCH (LEFT SIDE OF ENGINE, ABOVE STARTER)
FUEL PUMP/ SENDER ASSEMBLY (IN FUEL TANK)
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BLK WIRE
LOW REF
LT BLU/BLK WIRE
LT GRN/BLK WIRE
OIL PRESSURE SW
ORG/BLK WIRE
PPL
SIDE OF ENGINE COMPT, FRONT OF BATTERY)
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> SIDE OF ENGINE COMPT, FRONT OF BATTERY)
