Saturn Aura I (2006-2010) rly logic ctrl Wiring diagram
This page shows the only wiring diagram for the component.rly logic ctrl, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rly logic ctrl (1 of 1)
A/C CLU FUSE 1
A/C CLUTCH RELAY 34
ACCESSORY RELAY
BATTERY SENSE FUSE 54
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
COOL FAN 1 FUSE 17
COOL/FAN SER/PAR RELAY 29
COOLING FAN 1 RELAY 28
DK BLU WIRE
DOOR LOCK FUSE
DRIVER HEATED SEAT CONTROL MODULE
DRIVER HEATED SEAT SWITCH
DRIVER WINDOW SWITCH
FROM EPS FUSE 41 (DIAGRAM 1 OF 5)
IBCM 2 FUSE 25
INSIDE REARVIEW MIRROR (IF EQUIPPED)
INTERIOR LIGHTS FUSE
LOGIC
PASSENGER HEATED SEAT CONTROL MODULE
PASSENGER HEATED SEAT SWITCH
PASSENGER WINDOW SWITCH
PWR/TRN RELAY 33
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
RED WIRE
RLY LOGIC CTRL
ROOF/ HEAT SEAT FUSE
SUNROOF CONTROL MODULE
TO IBCM 1 FUSE 20 (DIAGRAM 3 OF 5)
TO POWER MIRRORS FUSE (DIAGRAM 4 OF 5)
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
W/ FRONT HEATED SEAT
W/ PANORAMIC SUNROOF
W/ STANDARD SUNROOF
WHT WIRE
WINDSHIELD DRIVER WIPER/ WINDOW SWITCH WASHER SWITCH
WIPER SW FUSE POWER WINDOWS FUSE
YEL WIRE
Go to component -> Power distribution circuit (2 of 5) -> RLY LOGIC CTRL
