Saturn Aura I (2006-2010) right rear marker lamp Wiring diagrams
This page contains all the electrical diagrams for the component. right rear marker lamp, in which he is found in the car Saturn Aura I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear marker lamp (1 of 2)
3.6L DK DK 3.5L
BATT POSITIVE VOLT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
CENTER CONSOLE
CLUSTER/ THEFT FUSE
COMPUTER DATA LINES SYSTEM HIGH SPD SERIAL DATA -
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (ECM) (3.5L/3.6L: LEFT SIDE OF ENGINE
GRN WIRE
HIGH SPD SERIAL DATA -
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT MARKER LAMP RIGHT FRONT MARKER LAMP
LEFT REAR TURN SIGNAL LAMP LEFT REAR MARKER LAMP
LEFT SIDE NEAR DASH)
LEFT TAIL/ STOP LAMP
LEFT TURN IND
LICENSE LAMP
LOGIC
LOW SPD SPD SERIAL SERIAL DATA DATA 2.4L (VIN B) 2.4L (VIN 5)
LT BLU WIRE
LT LT LT
PRK LAMPS FUSE 6
PRK LMP SUPPLY VOLT
PRK LP RELAY 27
REAR FUSE BLOCK
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
REAR SEAT AUDIO (RSA) CONTROL
RED WIRE
RIGHT REAR MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAIL/ STOP LAMP
RIGHT TURN IND
SERIAL BATT DATA
SERIAL DATA
STOP
STOP TAIL
TAIL
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
W/ REAR SEAT, EARPHONE JACKS RADIO CONTROL
WHEEL WELL)
WHT WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT REAR MARKER LAMP
Wiring diagram right rear marker lamp (2 of 2)
BLK WIRE
BODY CONTROL MODULE (BCM)
CENTER CONSOLE FLOOD LICENSE LAMP LAMP
CENTER HIGH MOUNTED STOP LAMP (CHMSL)
DIGITAL RADIO RECEIVER
FRONT OVERHEAD CONSOLE COURTESY/ DOME/ READING READING LAMPS LAMPS
FUEL/PUMP RELAY 37
IGNITION COIL/ MODULE 1
IGNITION COIL/ MODULE 2
IGNITION COIL/ MODULE 3
IGNITION COIL/ MODULE 4
INFLATABLE RESTRAINT PASSENGER PRESENCE SYSTEM (PPS) MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSIDE REARVIEW MIRROR
LEFT BACKUP LAMP
LEFT FRONT POWER DOOR STEERING COURTESY CONTROL LAMP MODULE
LEFT LEFT REAR TAIL/ TURN STOP SIGNAL LAMP LAMP
LEFT REAR MARKER LAMP
LEFT VANITY MIRROR LAMP
NCA WIRE
OUTSIDE REAR REARVIEW COMPARTMENT MIRROR LID RELEASE SWITCH SWITCH
R/WDO DEFOG RELAY 26
REAR COMPARTMENT LID LATCH
REAR FUSE BLOCK (BEHIND LEFT
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
REAR WHEEL WELL)
RIGHT BACKUP LAMP
RIGHT REAR MARKER LAMP
RIGHT REAR TURN SIGNAL LAMP
RIGHT TAIL/ STOP LAMP
RIGHT VANITY MIRROR LAMP
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
SUNROOF SHADE SWITCH
SUNROOF SWITCH
W/ DIGITAL RADIO
W/ ONSTAR
W/ PANORAMIC ROOF
W/ POWER, VARIABLE EFFORT
WHT WIRE
Go to component -> Ground distribution circuit (3 of 3) -> RIGHT REAR MARKER LAMP
