Saturn Aura I (2006-2010) ppl low ref fuel tank sig Wiring diagram

17 3120 3121 380 5514 EXTERIOR LIGHTS SYSTEM 2501 2500 1161 1271 1057 1162 705 2700 COMPUTER DATA LINES SYSTEM 335 5069 2759 1310 COOLING FANS SYSTEM 459 3223 3122 AIR CONDITIONING SYSTEM 5 V REF 1 IAT SENS SIG LOW REF 5 V REF 2 A/C COMPR RLY A/C REF SIG LOW REF A/C REFRIGERANT PRESSURE SENSOR (ON A/C LINE) ACC VOLT ACCELERATOR PEDAL POSITION (APP) SENSOR (ACCELERATOR PEDAL BRACKET) BANK 2 SENSOR 2 (LOWER FRONT OF ENGINE COMPT, CATALYTIC CONVERTER OUTPUT) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH) BRN WIRE BRN/WHT WIRE COOLING FANS SYSTEM CRUISE CONTROL SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/WHT WIRE ECM FUSE 51 ECM IGN FUSE 3 ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, FRONT OF BATTERY) FAN RLY CTRL PWR RLY CTRL LOW REF EVAP VENT FUEL PUMP RLY GRY WIRE GRY/WHT WIRE HEATED OXYGEN HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH IAT IGN 1 VOL VSS IGN 1 VOLT LOGIC LT BLU WIRE MAF MAF SENS SIG MASS AIR FLOW (MAF)/INTAKE AIR TEMPERATURE (IAT) SENSOR (OUTLET OF AIR CLEANER) MIL CTRL PPL NCA WIRE OFF ORG/BLK WIRE ORG/WHT WIRE PNK WIRE PNK/BLK WIRE POWER DISTRIBUTION SYSTEM PPL PPL FUEL LEVEL SENS FAN RLY CTRL ACC VOL IGN 1 VOL BATT POS VOL PPL LOW REF FUEL TANK SIG PPL PNK WIRE PPL/WHT WIRE RED/WHT WIRE RLY COIL CTRL RUN WIRE RUN/ CRANK RELAY 32 STARTING/CHARGING SYSTEM STOP LMP SIG PPL TAN WIRE TAN/BLK WIRE TAN/WHT WIRE UNDERHOOD FUSE BLOCK WHT WIRE WHT/BLK WIRE YEL WIRE
