Saturn Aura I (2006-2010) pnk amplifier enable battery pos volt Wiring diagram
This page shows the only wiring diagram for the component.pnk amplifier enable battery pos volt, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk amplifier enable battery pos volt (1 of 1)
10 VOLT REF
AMPLIFIER MUTE GROUND
AUDIO AMP FUSE 13
AUDIO AMPLIFIER (REAR COMPT, BELOW RIGHT TAILLIGHT)
BLK WIRE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT SPEAKER
LEFT REAR SPEAKER
LF SPEAKER OUT (-) LR SPEAKER OUT (-) LR SUB SPKR OUT (-)
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/WHT WIRE
NCA WIRE
ORG/ WIRE
PARK LAMPS SPLY VOLT
PNK AMPLIFIER ENABLE BATTERY POS VOLT WIRE
PNK WIRE
PPL
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
REAR SEAT AUDIO (RSA) CONTROLLER (W/ REAR SEAT, EARPHONE JACKS RADIO CONTROL)
RED WIRE
RED/WHT WIRE
RF SPEAKER OUT (-) RR SPEAKER OUT (-) RR SUB SPKR OUT (-)
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR SPEAKER
SUBWOOFER
TAN WIRE
TWEETER
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Radio circuit, enhanced (2 of 2) -> PNK AMPLIFIER ENABLE BATTERY POS VOLT WIRE
