Saturn Aura I (2006-2010) low sig Wiring diagrams
This page contains all the electrical diagrams for the component. low sig, in which he is found in the car Saturn Aura I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
low sig wiring diagram (1 of 3)
2-3 SHIFT SOL VLV CTRL
4-3 SHIFT SOL VLV CTRL
ACC VOLTAGE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT, BEHIND BATTERY)
FLUID PRESSURE TRANSMISSION
GMLAN DATA + GMLAN DATA -
GMLAN DATA - GMLAN DATA + SW SIG P HI CTRL VSS HI SIG STOP LAMP
GROUND
GRY WIRE
LOW SIG
LT BLU/WHT WIRE
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON TRANSMISSION, BELOW MASTER CYLINDER)
PNK WIRE
PPL
PPL VSS LO SIG LOW CTRL
RED/WHT WIRE
SW SIG A
SW SIG A LOW REF IGN 1 BATTERY SW SIG C
SW SIG B
SW SIG C
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TCC REL SW SIG
TFT SENS SIG
TRANSMISSION CONTROL MODULE (TCM)
VEHICLE SPEED SENSOR (VSS) (ON TRANSMISSION, AT FRONT, REAR SIDE OF ENGINE)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.4l vin 5, transmission circuit (1 of 2) -> LOW SIG
