Saturn Aura I (2006-2010) long yaw rate accel sens ref ref sig sig Wiring diagram
This page shows the only wiring diagram for the component.long yaw rate accel sens ref ref sig sig, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram long yaw rate accel sens ref ref sig sig (1 of 1)
2501 2501 COMPUTER DATA LINES SYSTEM
BATT ABS FUSE 56
BATT POSITIVE VOLT SERIAL DATA + SERIAL DATA +
BLK WIRE
BLU WIRE
BRAKE PRESSURE MODULATOR VALVE (BPMV)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK DK
DK GRN WIRE
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LAT ACCEL SIG
LATERAL ACCELEROMETER SIG YAW RATE DIAGNOSTIC
LEFT REAR WHEEL SPEED SENSOR (WSS) (LEFT REAR WHEEL HUB)
LF WHEEL SPD SENS SIG LF WHEEL SPD SENS LOW REF
LONG YAW RATE ACCEL SENS REF REF SIG SIG
LT BLU WIRE
ORG/ WIRE
PPL
PPL LOW REF YAW RATE SENS VOLT REF
RED WIRE
RED/WHT WIRE
RF WHEEL SPD SENS SIG RF WHEEL SPD SENS LOW REF
RIGHT REAR WHEEL SPEED SENSOR (WSS) (RIGHT REAR WHEEL HUB)
SERIAL DATA BUS (+) SERIAL DATA BUS (-)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
WHT WIRE
YAW RATE DIAGNOSTIC
YAW RATE SENS SIG LONGITUDINAL ACCELEROMETER SIG
YEL WIRE
YEL/BLK WIRE
Go to component -> Anti-lock brakes circuit, hybrid with traction control (1 of 2) -> LONG YAW RATE ACCEL SENS REF REF SIG SIG
