Saturn Aura I (2006-2010) keypad green led sig Wiring diagram
This page shows the only wiring diagram for the component.keypad green led sig, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram keypad green led sig (1 of 1)
AMBIENT LIGHT SENSOR (WINDSHIELD SIDE)
BACKUP LAMP SUPPLY VOLTAGE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
BRN/WHT WIRE
BUTTON BACK LIGHTING
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN/WHT WIRE
ELECTROCHROMIC
EMERGENCY
EMERGENCY IND
GROUND
GRY WIRE
HEADLIGHT SENSOR (MIRROR SIDE)
HIGH SENSITIVITY SETTING
HOT W/ ACCESSORY RELAY ENERGIZED
INSIDE REARVIEW MIRROR
KEYPAD GREEN LED IND
KEYPAD GREEN LED SIG
KEYPAD RED WIRE
KEYPAD SIGNAL
KEYPAD SUPPLY VOL
LED IND ONSTAR KEYPAD
LED SIG
LOGIC
LOW SENSITIVITY SETTING
LT GRN/BLK WIRE
MAX
OFF MIN
ONSTAR
ONSTAR IND
PHONE
PHONE IND
POWER DISTRIBUTION SYSTEM
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
REFLECTIVITY IN REVERSE
RESETS TO DAYTIME HIGH
ROOF/HEAT SEAT FUSE
YEL WIRE
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit -> KEYPAD GREEN LED SIG
