Saturn Aura I (2006-2010) hvac blower control motor control module module Wiring diagram
This page shows the only wiring diagram for the component.hvac blower control motor control module module, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hvac blower control motor control module module (1 of 1)
ADJUSTABLE PEDAL POSITION SWITCH (IF EQUIPPED)
AUTOMATIC A/C MANUAL A/C
BLK WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
COOL FAN 2 FUSE 18
COOL/ FAN 2 RELAY 30
DRIVER SEAT ADJUSTER SWITCH
DRV SEAT FUSE 2
EMISSION 2 FUSE 5
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID VALVE
FROM DOOR LOCK FUSE (DIAGRAM 2 OF 5)
FROM HORN FUSE 8 (DIAGRAM 3 OF 5)
FROM R/WDO DEFOG RELAY 26 (DIAGRAM 1 OF 5)
FRT FOG LP FUSE 10
FRT FOG RELAY 36
FUEL PUMP FUSE 25
FUEL/ PUMP RELAY 37
GENERATOR BATTERY ASSEMBLY
GENERATOR BATTERY DISCONNECT CONTROL MODULE
HVAC BLOWER CONTROL MOTOR CONTROL MODULE MODULE
HVAC BLOWER HIGH RELAY
HVAC HVAC CTRL (IGN) FUSE BLOWER FUSE (MANUAL A/C)
LOGIC RLY CTRL
MANUAL A/C
ONSTAR FUSE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER SEAT ADJUSTER SWITCH (IF EQUIPPED)
PEDAL FUSE
POWER MIRRORS FUSE
PRK LAMPS FUSE 6
PRK LP RELAY 27
PSG SEAT FUSE 1
RBEC 2 FUSE 23
RED WIRE
RELAY
RUN RLY FUSE 19
RUN WIRE
SLDG PNL ROOF FUSE 9
STOP LP FUSE 47
STOP LP RELAY 49
SUNROOF CONTROL MODULE
SUNROOF SHADE MODULE
TO STRTR FUSE 26 (DIAGRAM 5 OF 5)
TRUNK FUSE 22
TRUNK RELAY 36
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
W/ 2 WAY VERTICAL DRIVER POWER SEAT ADJUSTER W/ 8 WAY FRONT POWER SEAT ADJUSTER
WHT WIRE
WPR 1 RELAY 39
WPR FUSE 14
Go to component -> Power distribution circuit (4 of 5) -> HVAC BLOWER CONTROL MOTOR CONTROL MODULE MODULE
