Saturn Aura I (2006-2010) dr rev switch switch Wiring diagram
This page shows the only wiring diagram for the component.dr rev switch switch, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dr rev switch switch (1 of 1)
2-3 SHIFT SOLENOID (2-3 SS) VALVE
4-3 SHIFT SOLENOID (4-3 SS) VALVE
ACC VOLTAGE
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION FLUID PRESSURE (TFP) MANUAL VALVE POSITION SWITCH
AUTOMATIC TRANSMISSION FLUID TEMPERATURE (TFT) SENSOR
AUTOMATIC TRANSMISSION INPUT SHAFT SPEED (A/T ISS) SENSOR
BLK WIRE
BLK/ YEL WIRE
BODY CONTROL MODULE (BCM) LOGIC (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DR REV SWITCH SWITCH
GMLAN DATA
GRY WIRE
HOT AT ALL TIMES
IGNITION SWITCH
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
OFF
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PRESSURE CONTROL (PC) SOLENOID VALVE
RED WIRE
RED/WHT WIRE
RLY COIL CTRL
RUN WIRE
RUN/ CRANK RELAY 32
TAN WIRE
TAN/BLK WIRE
TCC RELEASE SWITCH
TCM FUSE 42
TRANS FUSE 4
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> 2.4l vin 5, transmission circuit (2 of 2) -> DR REV SWITCH SWITCH
