Saturn Aura I (2006-2010) cargo lp diode 38 wiring diagram
This page shows the only wiring diagram for the component.cargo lp diode 38, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
cargo lp diode 38 wiring diagram (1 of 1)
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
CARGO LP DIODE 38
CENTER CONSOLE FLOOD LAMP
COURTESY VOLT
CTSY LP CTRL
DOME LAMP
DOME/ READING LAMPS
DOOR
DOOR AJAR
DRIVER DOOR LATCH AJAR ASSEMBLY (REAR OF DRIVER DOOR)
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
INTERIOR LIGHTS FUSE
LEFT DOOR COURTESY LAMP
LEFT READING LAMP
LEFT REAR DOOR LATCH ASSEMBLY AJAR (REAR OF LEFT REAR DOOR)
LEFT REAR READING LAMP (IF EQUIPPED)
LEFT VANITY
LF DOOR AJAR
LOGIC
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR LAMP
OFF
ON OFF
ON OFF DOOR
ORG/ WIRE
ORG/BLK WIRE
OVERHEAD CONSOLE COURTESY/ READING LAMPS
PASSENGER DOOR LATCH AJAR ASSEMBLY (REAR OF FRONT PASSENGER
PPL
PPL (OR PPL)
PRK LAMPS FUSE 6
PRK LP CTRL
PRK LP RELAY 27
REAR COMPARTMENT COURTESY LAMP
REAR COMPARTMENT LID LATCH (CENTER REAR COMPARTMENT LID)
REAR FUSE BLOCK
REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
REAR LID AJAR
RIGHT DOOR COURTESY LAMP
RIGHT READING LAMP
RIGHT REAR DOOR LATCH ASSEMBLY AJAR (REAR OF RIGHT REAR DOOR)
RIGHT REAR READING LAMP
RIGHT VANITY MIRROR LAMP
TAN WIRE
TAN/WHT WIRE
W/ SUNROOF
W/O SUNROOF
WHT WIRE
Go to component -> Courtesy lamps circuit -> CARGO LP DIODE 38
