Saturn Aura I (2006-2010) antenna ground antenna sig Wiring diagram
This page shows the only wiring diagram for the component.antenna ground antenna sig, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram antenna ground antenna sig (1 of 1)
2061 2062 813 2 1 8 LOW REF VOICE SIG DRAIN WIRE
ANTENNA GROUND ANTENNA SIG
BARE
BATTERY POS VOLT
BLK WIRE
BLUNT CUT)
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
DIGITAL RADIO RECEIVER (UNDER REAR SHELF)
DK GRN WIRE
DK GRN/WHT WIRE
GMLAN SER DATA GMLAN SER DATA
GRN WIRE
GROUND AUDIO COMMON DRAIN WIRE
HOT AT ALL TIMES REAR FUSE BLOCK (BEHIND LEFT REAR WHEEL WELL)
LT AUDIO SIG (+) RT AUDIO SIG (+)
ORG/BLK WIRE
PNK/BLK WIRE
POWER DISTRIBUTION SYSTEM
RADIO
RED WIRE
RED/WHT WIRE
RKE/XM FUSE 16
TAN/WHT WIRE
WHT WIRE
Go to component -> Satellite radio circuit -> ANTENNA GROUND ANTENNA SIG
