Saturn Aura I (2006-2010) air conditioning system computer data lines system air conditioning system wiring diagram
This page shows the only wiring diagram for the component.air conditioning system computer data lines system air conditioning system, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
air conditioning system computer data lines system air conditioning system wiring diagram (1 of 1)
ACCESSORY VOLTAGE
AIR CONDITIONING SYSTEM
AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM
BATTERY POSITIVE VOLTAGE
BATTERY POSITIVE VOLTAGE BLOWER MTR SUPPLY VOLTAGE
BATTERY POSITIVE VOLTAGE I/P LAMP SUPPLY VOLTAGE
BLK WIRE
BLOWER MTR SUPPLY VOLTAGE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRN WIRE
DK BLU WIRE
ELECTRONIC POWER STEERING SYSTEM
GROUND
GRY WIRE
I/P LAMP SUP VOLTAGE I/P LAMP SUP VOLTAGE 3 BATTERY POSITIVE VOLTAGE
I/P LAMP SUPPLY VOLTAGE
IGNITION 3 VOLTAGE
INSTRUMENT CLUSTER SYSTEM ANTI-THEFT SYSTEM
LOGIC
LT GRN WIRE
ORG/ WIRE
PNK (NOT USED) PNK IGNITION 1 VOLTAGE IGNITION 1 VOLTAGE IGNITION 1 VOLTAGE WIRE
PNK IGNITION 1 VOLTAGE WIRE
PNK PNK PPL IGNITION 1 VOLTAGE WIRE
POWER DISTRIBUTION SYSTEM
POWER DISTRIBUTION SYSTEM ANTI-THEFT SYSTEM
POWER DISTRIBUTION SYSTEM INSTRUMENT CLUSTER SYSTEM
RED/BLK WIRE
RED/WHT WIRE
REMOTE RADIO CTRL SIG BLOWER MOTOR HIGH CTRL PARK LAMP SUPPLY VOLTAGE
SOUND SYSTEMS
SUPPLEMENTAL RESTRAINTS SYSTEM
WINDSHIELD WASHER PUMP CTRL I/P LAMP SUPPLY VOLTAGE
WIPER/WASHER SYSTEM INTERIOR LIGHTS SYSTEM
WIPER/WASHER SYSTEMS
YEL WIRE
Go to component -> Body control modules circuit (3 of 4) -> AIR CONDITIONING SYSTEM COMPUTER DATA LINES SYSTEM AIR CONDITIONING SYSTEM
