Saturn Aura I (2006-2010) 56 62 off/run crank voltage Wiring diagram
This page shows the only wiring diagram for the component.56 62 off/run crank voltage, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 56 62 off/run crank voltage (1 of 1)
2.4L (VIN 5) 2.4L (VIN B) 3.5L
2.4L (VIN 5), 3.6L 2.4L (VIN B) 3.5L
3.5L EXCEPT 3.5L
3.6L
3.6L, 2.4L (VIN 5) 3.5L
56 62 OFF/RUN CRANK VOLTAGE
AUTOMATIC TRANSMISSION
BATTERY
BLK WIRE
BLU WIRE
BLU/BLK WIRE
CHARGING CIRCUIT
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
EXCEPT 3.6L
EXCEPT 6 SPEED A/T 6 SPEED A/T 3 20
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
IGN SENSOR FUSE
IGNITION 1
IGNITION SWITCH
INTERNAL MODE SWITCH
KEY-IN IGNITION SWITCH
LOGIC
OFF
ORG/ WIRE
ORG/BLK WIRE
PARK/NEUTRAL POSITION (PNP) SWITCH (ON TRANSMISSION, BELOW MASTER CYLINDER)
PARK/NEUTRAL SIG
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL/WHT WIRE
RED WIRE
RELAY 31
RUN WIRE
STARTER MOTOR
STARTER RLY COIL CTRL
STRTR FUSE 26
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT, NEXT TO BATTERY)
WHT WIRE
WHT/BLK WIRE
Go to component -> Starting circuit -> 56 62 OFF/RUN CRANK VOLTAGE
