Saturn Aura I (2006-2010) 5 volt low reference reference Wiring diagram
This page shows the only wiring diagram for the component.5 volt low reference reference, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 5 volt low reference reference (1 of 1)
5 VOLT LOW REFERENCE REFERENCE
A/T SHIFT LOCK CONTROL SOLENOID (IN SHIFTER ASSEMBLY)
A/T SHIFT LOCK CTRL SOLENOID SUPPLY VOLTAGE
BATTERY
BLK WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE, LEFT SIDE NEAR DASH)
BRAKE PEDAL POSITION SENSOR (RIGHT SIDE BRAKE PEDAL BRACKET)
BRAKE PEDAL POSITION SENSOR SIGNAL
BRN WIRE
DK GRN WIRE
DOOR LOCK FUSE
GROUND
HOT AT ALL TIMES
INTERIOR LIGHTS FUSE
LOGIC
LT GRN WIRE
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> 5 VOLT LOW REFERENCE REFERENCE
