Saturn Aura I (2006-2010) 43 31 29 7 32 61 starter rly park/neutral sig Wiring diagram
This page shows the only wiring diagram for the component.43 31 29 7 32 61 starter rly park/neutral sig, which is found in the car Saturn Aura I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 43 31 29 7 32 61 starter rly park/neutral sig (1 of 1)
2.4L (VIN B)
2.4L (VIN B) 3.6L 3.5L
3.5L 2.4L (VIN B), 3.6L
3.5L 3.6L
3.6L, 2.4L (VIN 5) 3.5L
43 31 29 7 32 61 STARTER RLY PARK/NEUTRAL SIG
7 8 SERIAL DATA SERIAL DATA
BATTERY
BATTERY CURRENT SENSOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (CENTER CONSOLE,
BRN WIRE
CHARGE IND
CLUSTER/ THEFT FUSE
COMPUTER DATA LINES SYSTEM
DATA BUS -
DK GRN WIRE
ENGINE CONTROL MODULE (ECM) (2.4L (VIN 5): LEFT SIDE OF
FUSIBLE LINK (12 GA-
GENERATOR
GRY WIRE
HIGH SPEED GMLAN SERIAL DATA BUS +
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT SIDE NEAR DASH)
LOGIC
LOW REF
ORG/ WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
SENS SIG
SERIAL IGN DATA BATTERY POSITION VOLTAGE
STARTER MOTOR
TAN WIRE
TAN/BLK WIRE
VOLT
WHT WIRE
Go to component -> Charging circuit -> 43 31 29 7 32 61 STARTER RLY PARK/NEUTRAL SIG
